Dsp Flange Yokes

Part Number 1402-7566

  • Series: 1100
  • Pilot Type: F
  • Pilot Diameter: 1.650
  • Bolt Circle Diameter: 2.440
  • Bolt Hole Count: 6
  • Bolt Hole Diameter: 0.236
  • Centerline To Face: 1.500
  • Swing Diameter: 2.953
  • Notes: Metric 75mm/6mm
  • Vehicle Class: LD
  • Brand: PTI
Part Story

This is a European DIN flange built with 1100 series ears.

DIN is the equivalent of the SAE standard in the United States. DIN flanges center on the outside diameter and therefore do not have a traditional pilot measurement.

This flange can be found on printing presses and industrial machines.
