Part Story

Dsp Flange Yokes

Part Number 3102-42X

  • Series: 1310
  • Pilot Type: OD
  • Pilot Diameter: 4.250
  • Bolt Circle Diameter: 3.700
  • Bolt Hole Count: 6
  • Bolt Hole Diameter: 0.410
  • Centerline To Face: 2.750
  • Swing Diameter: 4.250
  • Notes: 6 Bolt Holes, Nissan 300ZX CVJ Conversion. hardware included (3173-42), 108mm OD, 93.6mm BC
  • Vehicle Class: LD
  • Brand: PTI
Part Story

This 1310 Nissan conversion flange replaces the CV joint in the rear of late model Nissan 300ZX turbo shafts.

This 6 bolt flange fits into the factory pinion flange that originally accepted the CV.

Bolt kit included.
