Part Story

Dsp End Yokes

Part Number 3504-07

  • Series: 1350
  • Spline Count: 30
  • Spline Diameter: 1.328
  • Hub Diameter: 1.739
  • Thru Hole: 1.200
  • Centerline To End: 3.375
  • Style: UB
  • Diff Model: GM 8.875
  • Vehicle Class: LD
  • Brand: PTI
Part Story

This forged yoke fits the GM 12 bolt (8.875") differential. It takes the Dana u-bolt kit number 3-94-18X. This yoke is cut deep to allow up to 30 degrees of angle for the off road specialist.

Applications for the 12 bolt 8.875"

1/2 Ton GM Pickup: 1963 - 1981 (Rear)
1/2 Ton GM Van: 1963 - 1981 (Rear)
Blazer: 1969 - 1981 (Rear)
Suburban 1/2 Ton: 1969 - 1981 (Rear)
Camaro: 1967 - 1972 (Rear)
Nomad: 1964 - 1972 (Rear)
Nova: 1964 - 1972 (Rear)

**RED FLAG... older catalog states this part comes with pinion nut and ubolts. It no longer does**
