Part Story
Dsp Flange Yokes
Part Number 3502-0145
- Series: 1350
- Pilot Type: F
- Pilot Diameter: 0.551
- Bolt Circle Diameter: 4.134
- Bolt Hole Count: 6
- Bolt Hole Diameter: 0.559
- Centerline To Face: 3.000
- Swing Diameter: 5.450
- Notes: Aluminum Tri Flange, 14mm nose hole, 3x14mm bolt holes on 105mm (4.134), 3x14 holes on 110mm (4.331), GM apps
- Vehicle Class: LD
- Brand: PTI
